Kawasaki KZ, ZX & ZN 1000-1100cc Motorcycle (1981-2002) Service Repair Manual

This item will be dispatched directly by Haynes and will arrive separately from any other parts ordered.

Clymer motorcycle repair manuals are written specifically for the do-it-yourself enthusiast. From basic maintenance to troubleshooting to complete overhaul, Clymer manuals provide the information you need. The most important tool in your tool box may be your Clymer manual, get one today.Every Clymer manual contains hundreds of original photographs and illustrations developed from a complete disassembly and assembly of a motorcycle. This, in addition to extensive research, allows Clymer to achieve an unmatched level of detail, accuracy and clarity.The step-by-step instructions and two-column text with large print are user-friendly. Bold figure numbers make it easy to quickly match instructions with illustrations and photos. Thumb-tabbed chapters, numbered table of contents and an extensive index make it possible to locate the desired section quickly.

What’s Covered

THIS KAWASAKI MOTORCYCLE MANUAL IS 376 PAGES.

• QUICK REFERENCE DATA
• CHAPTER ONE / GENERAL INFORMATION

MANUAL ORGANIZATION / SERVICE HINTS / SAFETY FIRST / EXPENDABLE SUPPLIES / SHOP TOOLS / EMERGENCY TOOL KIT / TROUBLESHOOTING AND TUNE-UP EQUIPMENT / SPECIFICATIONS

• CHAPTER TWO / TROUBLESHOOTINGSTARTING DIFFICULTIES / POOR PERFORMANCE / CLUTCH AND TRANSMISSION / DRIVE TRAIN / CHASSIS / BRAKES / ELECTRICAL SYSTEM / CHARGING SYSTEM / LIGHTING / FUSES / WIRING / SPECIFICATIONS
• CHAPTER THREE / LUBRICATION, MAINTENANCE AND TUNE-UPMODEL IDENTIFICATION / SCHEDULED MAINTENANCE / ENGINE OIL AND FILTER / DRIVE CHAIN LUBRICATION / SWING ARM LUBRICATION / STEERING HEAD LUBRICATION / WHEEL BEARING LUBRICATION / SHAFT DRIVE LUBRICATION / GENERAL LUBRICATION / BATTERY / AIR FILTER / CLUTCH ADJUSTMENT / DRIVE CHAIN ADJUSTMENT / STEERING PLAY INSPECTION / FRONT FORKS / REAR SHOCK ABSORBERS (DUAL SHOCK MODELS) / REAR SHOCK ABSORBERS (UNI-TRACK MODELS / TIRES / WIRE WHEELS / CAST WHEELS / DISC BRAKE / NUTS, BOLTS AND FASTENERS / ENGINE TUNE-UP / FUEL SYSTEM / SPARK PLUGS / AIR SUCTION VALVES / VALVE CLEARANCE / IGNITION TIMING / CARBURATION OR FUEL INJECTION / CYLINDER COMPRESSION / STORAGE / SPECIFICATIONS
• CHAPTER FOUR / ENGINEBREAK-IN / CAM CHAIN AND TENSIONER / VALVE COVER / CAMSHAFTS / CYLINDER HEAD / VALVES AND VALVE COMPONENTS / CYLINDER BLOCK / PISTONS AND RINGS / OIL COOLER / REMOVAL INSTALLATION / OIL PUMP / CRANKCASE / CRANKSHAFT AND CAM CHAIN / CRANKCASE ASSEMBLY / SPECIFICATIONS
• CHAPTER FIVE / CLUTCHOPERATION / CLUTCH RELEASE / OVERHAUL / SPECIFICATIONS
• CHAPTER SIX / TRANSMISSIONSPROCKET COVER / ENGINE SPROCKET / NEUTRAL SWITCH / SHIFT LINKAGE / SHIFT DRUM AND FORKS / TRANSMISSION GEARS / FRONT BEVEL DRIVE / SPECIFICATIONS
• CHAPTER SEVEN / CARBURETION AND EXHAUST SYSTEMSCARBURETOR OPERATION SERVICE TROUBLESHOOTING / REJETTING / FUEL LEVEL INSPECTION / IDLE MIXTURE ADJUSTMENT / CRANKCASE BREATHER / AIR SUCTION SYSTEM / FUEL TANK / FUEL TAP / FUEL LEVEL SENDING UNIT / EXHAUST SYSTEM / SPECIFICATIONS
• CHAPTER EIGHT / FUEL INJECTION SYSTEMFUEL INJECTION OPERATION / FUEL INJECTION PRECAUTIONS / FUEL INJECTION SCHEDULED MAINTENANCE / FUEL INJECTION TESTING / QUICK DIAGNOSIS / FUEL SYSTEM TESTS / CONTROL UNIT SYSTEM TESTS / SENSOR TESTS / SIGNAL TEST / LAST CHANCE / FUEL INJECTION DISASSEMBLY / CONTROL UNIT / SPECIFICATIONS
• CHAPTER NINE / ELECTRICAL SYSTEMFUSES / BATTERY / IGNITION SYSTEM / SPARK PLUGS / IGNITION COILS / PICKUP COILS / IGNITION ADVANCE MECHANISM / IC IGNITER / CHARGING SYSTEM / ALTERNATOR / STARTING SYSTEM / STARTER MOTOR / STARTER CLUTCH / STARTER SOLENOID / STARTER LOCKOUT SWITCH / LIGHTING SYSTEM / TURN SIGNAL CANCELLING SYSTEM / FUEL GAUGE / FUEL LEVEL SENSOR / ELECTRIC INSTRUMENTS / TACHOMETER/VOLTMETER / ELECTRONIC WARNING UNIT / HORN / VOLTMETER / SPECIFICATIONS
• CHAPTER TEN / WHEELS, TIRES AND BRAKESWIRE WHEELS / CAST WHEELS / FRONT REAR WHEEL / WHEEL BEARINGS AND SEALS / AXLE / BRAKES / BRAKE SYSTEM BLEEDING / BRAKE FLUID CHANGE / BRAKE HOSE / BRAKE PADS AND CALIPERS / FRONT REAR MASTER CYLINDER / BRAKE DISCS / SPECIFICATIONS
• CHAPTER ELEVEN / CHASSISFAIRING / HANDLEBARS / FRONT FORKS / STEERING / SHOCK ABSORBERS / SWING ARM / UNI-TRACK REAR SUSPENSION / DRIVE CHAIN / FINAL GEAR CASE / SWING ARM / DRIVE SHAFT / SPECIFICATIONS
• SUPPLEMENT / 1982-2002 POLICE MODEL SERVICE INFORMATION
• INDEX
• WIRING DIAGRAMS
• MODELS COVERED:1981-1982 KAWASAKI KZ1000 KZ 1000 J1, J2 STANDARD (US AND CANADA)1981-1982 KAWASAKI KZ1000 KZ 1000 K1, K2 LTD (US AND CANADA)1981-1982 KAWASAKI KZ1000 KZ 1000 M1, M2 CSR (US AND CANADA)1982-1983 KAWASAKI KZ1000 KZ 1000 R1, R2 REPLICA (US AND CANADA)1981-1983 KAWASAKI KZ1100 KZ 1100 A1, A2, A3 STANDARD (US AND CANADA)1981-1982 KAWASAKI KZ1100 KZ 1100 B1, B2 GP (US AND CANADA)1982-1983 KAWASAKI KZ1100 KZ 1100 D1, D2 SPECTRE (US AND CANADA)1983 KAWASAKI KZ1100 KZ 1100 L1 LTD-SHAFT (US AND CANADA)1981 1982 KAWASAKI Z1000 Z 1000 J1, J2 (OTHER THAN US AND CANADA)1981 1982 KAWASAKI Z1000 Z 1000 K1, K2 (OTHER THAN US AND CANADA)1982 1983 1984 1985 1986 1987 1988 1989 1990 1991 1992 1993 1994 1995 1996 1997 1998 1999 2000 2001 2002 KAWASAKI Z1000 Z 1000 POLICE MODEL P1-P21 (US AND CANADA)1983 KAWASAKI Z1000 Z 1000 R2 (OTHER THAN US AND CANADA)1983 KAWASAKI Z1000J3 Z 1000 J3(OTHER THAN US AND CANADA)1981 1982 KAWASAKI Z1100 Z 1100 A1, A2 (OTHER THAN US AND CANADA)1983 1984 KAWASAKI Z1100 Z 1100 A1, A2 (OTHER THAN US AND CANADA)1985 KAWASAKI Z1100 Z 1100 A3 (OTHER THAN US AND CANADA)1981 1982 KAWASAKI Z1100 Z 1100 B1, B2 (OTHER THAN US AND CANADA)1983 KAWASAKI Z1100 Z 1100 D2 (OTHER THAN US AND CANADA)1984 1985 KAWASAKI ZN1100 Z 1100 B1, B2 (US AND CANADA)1983 1984 KAWASAKI ZX1100 Z 1100 A1, A2 (US AND CANADA)
• CLYMER MANUALS KAWASAKI KZ1000 MANUALCLYMER MANUALS KAWASAKI KZ1100 MANUALCLYMER MANUALS KAWASAKI ZX1100 MANUALCLYMER MANUALS KAWASAKI Z1000 MANUALCLYMER MANUALS KAWASAKI ZN1100 MANUALCLYMER MANUALS KAWASAKI Z1000 POLICE MODEL MANUAL
